LM2903Q2T /Код si-372249

LOW POWER COMPARATOR, DUAL, 1.3US, DFN-8; Comparator Type:Low Power; No. of Comparators:2 Comparators; Response Time:1.3µs; Supply Voltage Range:2V to 36V, ± 1V to ± 18V; Comparator Case Style:DFN; No. of Pins:8Pins; IC Output Type:CMOS, MOS, TTL, DTL, ECL; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Product Range:-; Automotive Qualification Standard:-; RoHS Phthalates Compliant:Yes; MSL:-; SVHC:No SVHC (07-Jul-2017); No. of Comparators:2

Brand	STMicroelectronics
Factory Pack Quantity	3000
GBP - Gain Bandwidth Product	-
Height	0.55 mm
High Level Output Current	0.1 nA
Ib - Input Bias Current	400 nA
Length	2 mm
Low Level Output Current	250 mV
Manufacturer	STMicroelectronics
Maximum Operating Temperature	+125 C
Minimum Operating Temperature	-40 C
Mounting Style	SMD/SMT
Number of Channels	2 Channel
Operating Supply Current	2.5 mA
Package / Case	DFN-8
Packaging	Tube
Product	Analog Comparators
Product Category	Analog Comparators
Response Time	13 us
RoHS	Details
Series	LM2903
Supply Voltage - Max	36 V
Supply Voltage - Min	1 V
Vos - Input Offset Voltage	15 mV
Width	2 mm
Base Product Number	LM2903 ->,
Current - Input Bias (Max)	0.25Вµ,A @ 5V
Current - Output (Typ)	16mA @ 5V
Current - Quiescent (Max)	2.5mA
ECCN	EAR99
HTSUS	8542.39.0001
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mounting Type	Surface Mount
Number of Elements	2
Operating Temperature	-40В°C ~ 125В°C
Output Type	CMOS, DTL, ECL, TTL
Package	Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ®,
REACH Status	REACH Unaffected
RoHS Status	ROHS3 Compliant
Supplier Device Package	8-DFN (2x2)
Type	Differential
Voltage - Input Offset (Max)	7mV @ 5V
Voltage - Supply, Single/Dual (В±)	2V ~ 36V, В±1V ~ 18V
кол-во в упаковке	3000
