LM4120AIM5-2.5 /Код si-332724

VOLTAGE REF, SERIES, 2.5V, SOT-23-5; Voltage Reference Type:Series - Fixed; Product Range:LM4120 Series; Reference Voltage:2.5V; Initial Accuracy:0.2%; Temperature Coefficient:± 14ppm/°C; Voltage Reference Case Style:SOT-23; No. of Pins:5Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (15-Jan-2019); Base Number:4120; Device Marking:LM4120AIM5-2.5; Input Voltage:3.3V to 12V; Input Voltage Max:12V; Input Voltage Min:3.3V; Junction Temperature Tj Max:85°C; Junction Temperature Tj Min:-40°C; Logic Function Number:4120; Operating Temperature Range:-40°C to +85°C; Power Dissipation Max:350mW; Reference Volt Tolerance ±%:0.2%; Reference Volts:2.5V; Temperature Coeff. +:50ppm/°C; Tolerance:0.2%; Topology:Series

Accuracy	0.12%/mA
Brand	Texas Instruments
Factory Pack Quantity	1000
Height	1.02 mm
Initial Accuracy	0.2%
Length	2.92 mm
Manufacturer	Texas Instruments
Maximum Operating Temperature	+85 C
Minimum Operating Temperature	-40 C
Mounting Style	SMD/SMT
Operating Supply Current	160 uA
Operating Temperature Range	-40 C to+85 C
Output Voltage	2.5 V
Package / Case	SOT-23
Packaging	Reel
Product	Voltage References
Product Category	Voltage References
Reference Type	Series Precision References
RoHS	Details
Series	LM4120
Series VREF - Input Voltage - Max	14 V
Shunt Current - Max	5 mA
Temperature Coefficient	50 PPM/C
Topology	Series References
Unit Weight	0.00709 oz
Width	1.6 mm
Input Voltage	2 V ~ 12 V
Output Current	5mA
Output Type	Fixed
Supply Current	275uA
Tolerance	В±0.2%
Вес, г	0.15
