VIPER16HN /Код si-187706

AC/DC преобразователи интегральныеAC/DC CONVERTER, 800V, 115KHZ, 7DIP; Input Voltage AC Min:85V; Input Voltage AC Max:265V; AC / DC Converter Case Style:DIP; No. of Pins:7Pins; Power Rating:10W; Topology:Flyback; Operating Temperature Min:-40°C; Operating Temperature Max:150°C; Product Range:-; RoHS Phthalates Compliant:Yes; MSL:-; SVHC:No SVHC (17-Dec-2015); Input Voltage:265VAC; No. of Outputs:1Outputs; Supply Voltage Max:23.5V; Supply Voltage Min:11.5V

Корпус	DIP7
кол-во в упаковке	50
Brand	STMicroelectronics
Duty Cycle - Max	80%
Factory Pack Quantity	2000
Input / Supply Voltage - Max	11.5 V
Input / Supply Voltage - Min	11.5 V
Isolation	Isolated/Non-Isolated
Manufacturer	STMicroelectronics
Maximum Operating Temperature	+150 C
Minimum Operating Temperature	-40 C
Mounting Style	Through Hole
Number of Outputs	1 Output
Operating Supply Current	1.5 mA
Output Current	420 mA
Output Power	12 W
Output Voltage	800 V
Package / Case	DIP-7
Packaging	Tube
Product Category	AC/DC Converters
RoHS	Details
Series	VIPer Plus
Switching Frequency	115 kHz
Topology	Buck-Boost, Flyback
Type	Current Mode PWM Controller
Вес, г	0.86
